Primary pilocytic astrocytoma of cerebello-pontine angle in the pediatric age group: literature review and case report

Abstract

Background

Primary pilocytic astrocytoma of the CPA (Cerebello-pontine angle), in the pediatric age group is an extremely rare entity, with just three cases reported so far. It mostly arises from the root entry zone of the cranial nerves found in this cistern.

Case presentation

A 11-year boy presented with headache, hearing impairment in right ear. Pure tone audiogram and BAER (Brainstem auditory evoked response) suggested retro-cochlear sensori-neural hearing loss. MRI revealed a heterogeneously enhancing extra-axial lesion in the right CPA. Tumor was approached through right retromastoid suboccipital craniotomy. Intraoperatively it seemed to arise from the REZ (root entry zone) of CN VIII and histopathology confirmed it to be pilocytic astrocytoma. We have reported this as only the fourth case and reviewed the already existing literature. In the previous case reports an extensive immunohistochemical analysis was not done and the final diagnosis was not as per the Harlem consensus guidelines.

Conclusion

In this case, we have tried to report the final histopathology in accordance with the 5th edition of WHO classification of CNS tumors. In the current era of molecular diagnosis and layered structural format of reporting a histopathology, this case is the first of its kind and emphasizes the need to consider PA as one of the differentials for lesions in CPA.

Background

Pilocytic astrocytoma constitutes 5–10% of primary pediatric tumors and is the most common intrinsic brain tumor in this age group. It is seen mostly in the cerebellum, brainstem, optic pathway, hypothalamus, and rarely in the cerebellopontine angle [1]. Primary pilocytic astrocytoma of CPA (cerebellopontine angle) has been found to arise from the REZ (root entry zone) of the cranial nerves found in this cistern [2, 3]. Such cases in the pediatric population are extremely rare [4,5,6]. With due consent of patient’s guardian we report this case as only the fourth pilocytic astrocytoma of CPA in the pediatric age group and the first of its kind in the era of molecular diagnosis.

Case report

A 11-year boy presented with decreased hearing in the right ear, occasional headache, and vomiting for 4 months. Neurological examination revealed SNHL (sensorineural hearing loss) in the right ear and bilateral papilledema. Although pure tone audiogram confirmed the presence of SNHL in the right ear, he had a serviceable hearing. And, BAER revealed a delay in wave V, thus suggesting a retro-cochlear pathology.

Neuroimaging

Preoperative MRI, revealed a well-circumscribed extra-axial lesion of in the right CPA, compressing the fourth ventricle, pons, medulla, right cerebellar hemisphere, vermis, and had upstream hydrocephalus (Fig. 1). The lesion showed heterogeneous contrast uptake, with a small focal extension into the right IAC and the right jugular foramen.

Fig. 1

Axial (a) and sagittal (b) views of contrast MRI showing a heterogeneously enhancing mass lesion [size 5.0 (TR) × 4.3 (AP) × 5.0 (CC) cm] in the right cerebellopontine angle. Axial T2 image (c) showing an extraaxial lesion in the right cerebellopontine angle, with focal extension into the internal auditory canal

Intraoperative findings

A left ventriculoperitoneal shunt was placed at first, followed by right RMSOC to expose the tumor. EMG was used to map out the course of CN VII. Tumor was encapsulated, grayish white, soft, and was moderately vascular. The central portion of tumor was debulked with the CUSA and as the capsule buckled in, the preserved arachnoidal planes aided in separating it from the cerebellum, brain stem, peduncles, and cranial nerves (V, IX, X). Carefully facial nerve could be dissected away from the tumor mass. However, the tumor was seen to be arising from the CN VIII, almost 1–2 cm away from the surface of the brainstem. The tumor could be excised completely except for a small segment that was adherent to the CN VIII (Fig. 2). The postoperative hospital stay was uneventful and at 18 months of follow-up he is asymptomatic and his hearing was still preserved.

Fig. 2

Postoperative CT head showing the tumour cavity and gross total resection of the tumour

Histopathology

Microscopic examination revealed cells that were ovoid to spindle-shaped, piloid in appearance, arranged in sheets, with no significant nuclear mitosis, atypia, necrosis, and microvascular proliferation. The background showed the presence of eosinophilic granular bodies and Rosenthal fibers. In view of morphology and IHC (Fig. 3) the final diagnosis of pilocytic astrocytoma (WHO grade 1) was made.

Fig. 3

a Histopathology slide (using Hematoxylin and eosin stain) shows cells that are spread in sheets, are ovoid to spindled and with no significant nuclear atypia. Many Rosenthal fibers are noted in the background (black arrows). Immunohistochemical analysis showed positivity for GFAP (b), suggesting a glial lineage. IDH1 immunonegative (c), ATRX expression retained (d), p53 expression heterogenous (e). The Ki67 index (2%) was low (f)

Discussion

Excluding NF2, extra-axial lesions in CPA in the pediatric age group are extremely rare. Most of the glial tumors in CPA are due to the secondary exophytic growth of cerebellar and brainstem gliomas. The literature has a handful of cases of gliomas in CPA that are exclusively extra-axial. Most of these have been in the adult population and have either been reported as fibrillary glioma or non-specifically as ‘glioma’ [7, 8]. The source of origin has been the proximal segment of the cranial nerves seen in this anatomical cistern. It is vital to preoperatively differentiate an extra-axial CPA lesion from an intra-axial one as the goal of surgery varies accordingly. In our case, the clinical and radiological findings pointed toward vestibular schwannoma and RMSOC (retro mastoid suboccipital craniotomy) was done to explore the CPA [9]. Intraoperatively we found the lesion to have maintained a good anatomic plane with the brainstem and cerebellum however, it was focally adherent to the glial segment of CN VIII, suggesting it to be the site of origin. In a giant tumor, identification and mapping of the facial nerve using EMG is key to the preservation of its function [10]. Prior ventriculoperitoneal shunt not only relieved the intra-cranial pressure but also aided in preventing retraction injury to the cerebellum.

Panse [11] and Cushing [12] were the first to report cases of fibrillary astrocytomas arising from the root entry zone of CN VIII. Subsequently, many cases of CPA gliomas have been reported and the histological diagnoses have ranged from benign pilocytic astrocytoma to fibrillary astrocytoma to high-grade gliomas like glioblastoma. Specific diagnosis of Primary pilocytic astrocytoma in CPA has commonly been reported in adults [2, 3, 13]. However, only three such cases have been reported in the pediatric age group to date. Over the last decade, the advances in the molecular characteristics of brain tumors have led to the revision of brain tumor taxonomy and inception of immunohistochemical analysis and molecular typing for a comprehensive diagnosis. This case is the first of its kind in the era of molecular diagnosis. Arnautovic et al. [4] and Mirone et al. [5] have reported cases of PA in CPA, arising from the glial segment of CN V, but the final diagnosis was based entirely on the histomorphology. As per the fifth edition of WHO classification of CNS tumors (2021), we have performed all the necessary histological and IHC tests that are recommended for a tumor with glial lineage (Table 1). The final diagnosis was reported in the layered integrated structural format, as per the Harlem consensus guidelines [14].

Table 1 Briefly describes all the three cases of primary pilocytic astrocytoma of cerebellopontine angle in pediatric population

As the cranial nerves emerge from the brain stem, the REZ is subdivided into: the proximal glial segment (surrounded by the astrocytes and oligodendrocytes), the transitional zone, and the distal peripheral segment (surrounded by Schwann cells). Studies by Skinner and Tarlov showed that the glial segment is longest in CN VIII followed by the sensory division of CN V [15, 16]. Arnautovic et al. have proposed that, longer the glial outgrowth greater is the predisposition to gliomas and hence primary pilocytic astrocytoma of CPA arises most commonly from the CN VIII, followed by CN V [4]. However, dearth of cases has kept this hypothesis under the shadow of debate.

Conclusions

We have reported a rare pediatric case of a giant primary pilocytic astrocytoma of CPA, arising from the root entry zone of CN VIII. It is the largest of such tumors reported till date and certainly expands the differential diagnosis for CPA. Being a tumor with low grade features, its complete excision should be the goal for a recurrence free survival. The contentious topics like the diagnosis and origin of these tumors can be settled only by high degree of suspicion, meticulous analysis of imaging, intraoperative assessment, adequate histo-morphological and immunohistochemical analysis, and of course by increased reporting of such cases.
