Delayed return of urinary continence following the removal of neglected sacral shrapnel

Abstract

Background

Globalisation of terrorism has led to an increase in the number of injuries from the explosion of improvised explosive devices, with complications resulting from the retained shrapnel. It had been found that a third of those who sustained penetrating spinal cord injuries are from explosions. Retained foreign body in the sacral canal segment is rare, especially shrapnel presenting with urinary incontinence. Moreover, the one who had a dramatic recovery of urinary continence following removal of neglected sacral canal shrapnel. We report a case of a delayed improvement (recovery) in urinary continence following removal of neglected sacral canal shrapnel remotely aided by a pelvic floor exercise.

Case presentation

Our patient was a 14-year-old male who presented with a 3-year history of trauma to the lower back from an Improvised Explosive Device. He was initially associated with difficulty in walking that improved over eight months. However, the urinary incontinence persisted. He was found to be preserved with no neurological deficit in the lower limb. There was a lower back, midline wound, discharging pus. Lumbosacral imaging revealed a sacral (S2) canal Shrapnel. As a case of urinary incontinence from sacral shrapnel, he had the removal of the shrapnel, did well postoperatively, commenced on pelvic floor exercise. He became continence of urine over time.

Conclusions

Retained foreign bodies in the spinal canal are associated with complications that include neurological deficit. Neglected (long-standing) sacral shrapnel with urinary incontinence is rare; moreover, the recovery of the continence with the removal of the shrapnel is aided by the commencement of pelvic floor exercise.

Background

Shrapnel gets its name from General Henry Shrapnel of the British Army's Royal Artillery, who, during the Peninsular War, invented an exploding shell that breaks apart and shatter when it is detonated [1]. With the globalisation of terrorism, a significant concern, blast wounds from improvised explosive devices (IEDs) are frequently encountered outside the battlefield, resulting in numerous shrapnel injuries [2].

Following an explosion, gunshot injuries, or motor vehicle accident, penetration and retention of foreign bodies (including shrapnel) are pretty common. Likewise, Blair [3] et al. found that explosives are responsible for a third of those who sustain penetrating injury to the spine.

Foreign bodies in the sacrum are rare. However, there are reports of findings of a nail, wood, and glass [4,5,6], respectively.

Retained foreign body from within the spinal canal may result in complications like a cerebrospinal fluid leak, osteomyelitis, meningitis, migration of the foreign body, and progressive neurologic deficits [7]. Currently, there is a paucity of literature regarding the management and outcome of such injuries due to explosive mechanisms [8, 9]. Common English search engines could not return reports on removing sacral shrapnel and resultant spontaneous recovery of urinary continence. We report a case with urinary incontinence for three (3) years from a retained sacral shrapnel following an IED explosion. He became continence of urine after the surgery with pelvic floor exercise.

Case presentation

We report a 14-year-old boy referred to our facility with a 3-year history of urinary incontinence following trauma to his lower back from an Improvised Explosive Device (IED) explosion. Developed initial difficulty in walking that improved over eight months, currently ambulant. However, he had persistent urinary incontinence and residual low back wound. There was no loss of consciousness, faecal incontinence or feature suggestive of foot drop. Other systems were essentially normal. Medical, family and psychosocial histories are non-contributory.

Examination revealed a preserved but depressed-looking teenager, smelling of urine, afebrile, not pale, with stable vitals. Neurological examination revealed lower limbs muscle power of Medical Research Council (MRC) grade 5/5 in all the muscle groups; the sensation was preserved, with no saddle anaesthesia. Back examination revealed a lower back (sacral area) wound discharging pus, about 3 cm to the right of the midline, mildly tender, no palpable mass, as shown in Fig. 1a below. Digital Rectal Exam (DRE) indicated an excellent sphincter tone. Other systemic examinations were essentially normal.

Fig. 1
figure 1

The entry wound discharging pus (a), lumbosacral X-ray, anteroposterior view (b) and lateral (b) showing the shrapnel in the second sacral (S2) vertebra canal

Lumbosacral X-ray revealed an opacity of metallic density (shrapnel) in the Second Sacral (S2) canal, lying diagonally, as shown in Fig. 1b, c below in Fig. 1.

Wound swab Microscopy, Culture and Sensitivity (MCS) was sterile. His packed Cell Volume was 38%, Electrolyte, Urea, Creatinine and urinalysis were normal.

Lumbosacral Computed Tomography Scan (CT scan) with sagittal reconstruction showed a nearly rectangular hyper dense foreign body of metallic density in the spinal canal of S2, with defective dorsum and cauda equina compression as shown in Fig. 2a, b below in Fig. 2.

Fig. 2
figure 2

showing CT Scan findings of S2 canal metallic fragment in axial (a) and sagittal reconstructions (b), the intraoperative finding of dark colour shrapnel (c), the removed shrapnel (d)

He was counselled for surgical removal of the shrapnel under general anaesthesia. He was intubated with an "armoured" endotracheal tube, turned prone on bolsters around pressure points, cleaned and draped, exposing the sacral area. The shrapnel’s position was localised with the use of a C-arm fluoroscope. The sacrum was exposed through a midline incision, and a fractured part was found around the shrapnel. After enlarging the fractured entry point, the shrapnel was fully exposed (Fig. 2c) and removed. The removed shrapnel was a dark metal, nearly rectangular, about 30 mm long and 8 mm wide (as in Fig. 2d), as shown in Fig. 2 above.

The discharging sinus was excised, and tissue was sent for microscopy, culture and sensitivity, wound cleaned with dilute hydrogen peroxide (H2O2) and normal saline, wounds closed and dressed. No intra-operative or post-operative cerebrospinal fluid (CSF) leak was observed. He was placed on broad-spectrum antibiotics; the culture result was sterile. The wound healed with no residual infection.

He was commenced on pelvic floor exercise from the third day post-op, wound stitches removed on the tenth day and subsequently discharged home to continue pelvic floor exercise. At the second follow-up (about 8 weeks after the surgery), the patient reported an onset of urinary continence.

Discussion

Blast and gunshot-related injuries are common in countries where war/terrorist activities are prevalent, like in our setting, ravaged by civil-military conflict (Boko Haram terrorists). Such injuries are associated with retained shrapnel or bullets. Long-term complications of retained shrapnel depend on the anatomical location and interaction with the tissues.

Our patient presented with an incomplete spinal cord injury (urinary incontinence only) due to penetrating shrapnel from an IED blast. Such penetrations are said to be a fairly common finding, as reported by Blair [3] from studies in Iraq and Afghanistan, where he found that about one third (1/3) of penetrating spinal injuries are from explosions.

Presentations with a neurological deficit (urinary incontinence) and discharge of pus from the wound are some of the common complications that are likely among others; this agrees with the findings of Bhatoe [10].

Indications for surgical management of penetrating SCI include rapid neurological deterioration, radiographic evidence of spinal cord or nerve root compression, mechanical instability, abscess, cerebrospinal fluid (CSF) leakage, and chronic pain [11, 12].

Like any other metallic foreign body, the diagnosis was made from a plain radiograph and a computed tomography (CT) Scan of the Lumbosacral Spine. Shahlaie [13] had stressed the importance of CT scans in identifying the site, trajectory and planning of surgery.

The shrapnel was removed under general anaesthesia following localisation with fluoroscopy. Studies demonstrated that fluoroscopic image intensifier is a valuable and safe method to detect a foreign body (FB) preoperatively and intraoperatively [14, 15].

After the extraction of the neglected shrapnel and subsequent pelvic floor exercise, he noticed a gradual improvement in his continence, making us presume that he must have improved after the surgical intervention (removal of the shrapnel). The patient’s improvement in urinary continence within two (2) months of removing neglected shrapnel suggest that the surgery might have sped up the process. Though there were few studies on patients that improved clinically after undergoing similar intervention, our patient probably belongs to the 70% of patients that were found to have improved following surgical intervention, as reported by Lawless [16]. However, Lawless [16] found in the second group of his patients that as many as 81% had improved clinically without any form of surgical intervention; this is at variance with our patient who was incontinent for three (3) years before the surgical intervention. Worthy of note is the significant difference in duration of symptoms of his patients upon presentation averaging 2 weeks (early), compared to our patient that presented three (3) years after the injury (late).

Conclusion

Spinal Cord Injury (SCI) due to explosive shrapnel has increased in recent military conflicts. Contributing to this are increasing acts of terrorism, to a much higher degree than in any previous period. Despite recovering from a cauda equina syndrome three (3) years earlier, worthy of note is the persistence of urinary incontinence, which resolved about two (2) months after the removal of the neglected sacral shrapnel, aided probably by an active pelvic floor exercise.
